Starter Solenoid Relay Replacement for Kawasaki 27010-7005 27010-2122 Kohler 52-435-02S

Starter Solenoid Relay Replacement for Kawasaki 27010-7005 27010-2122 Kohler 52-435-02S

Solid-state starter solenoid relay suitable for a wide range of small engines and lawn equipment.

Replacement Part Numbers
Kohler 52-435-02S, 52-435-02, 5243502, 5243502S
Kawasaki 27010-2122, 27010-7005
Kubota 12181-63080
John Deere AM102577, MIU11504
Isuzu 8-94361-9080, 8-94455-1790
Denso 153400-990, 153400-9900, 053400-7130, 053400-8510, 053400-5180, 053400-8780
Toyota 28150-10020, 28150-10021, 28150-11710, 28150-11771, 28150-87208
Rotary 26-10262, 26-10241, 10683, 10806
KM-27010-0843, KM-27010-2122

Compatible Engines / Equipment
Kawasaki FB460V-AS32, FB460V-BS17, BS19, BS22, BS23, BS24, BS26, BS32, FB460V-CS16, ES03, FS03, GS03, HS04, FC400V-AS00, AS02, BS02, FC401V-AS00, AS02, FC420V-AS03, AS04, AS08, AS20, AS22, AS23, AS24, AS26, BS01, BS08; also compatible with equipment using the above OEM solenoid numbers from Kohler, John Deere, Kubota and Rotary.

Specifications
Type: Starter Solenoid Relay (Solid State Module)
Voltage: 12V

Note:
Please confirm that this solenoid relay is compatible with your starter motor before purchasing, especially the two-bolt mounting configuration.
